M01-SP

Information

New Era AI Robotic (NewERA) Disinfectant Spraying Robot integrates the delivery AMR with a spraying module which including four high-pressure nozzles to atomize disinfectant for complete coverage. The robot carries a 45-liter SUS405 container suitable for mild acid or bases disinfectant.  This smart disinfection solution can spray cover places like the floor, handrails, and seating areas day and night. A trained operator can use the APP to assign an area to be disinfected remotely without exposure to the environment. The Android APP can also set a task schedule, receive notification when water and the battery level is low, and be to monitor robot status.

Specification

Platform OS: Windows10 + Linux(Ubuntu)
CPU: Intel N-series (Windows) / Intel i3 U-series (Linux)
Battery: 25.2V/34.8Ah; 876Wh, 7S12P
Run/Charge Time: 4 hr / 6 hr
Max Speed: 0.58 (m/s)
Sensors LiDAR x 1, Ultrasonic x 7, IR x 2, RealSense x 1
WiFi: WiFi, IEEE a/b/g/n (2.4/5GHz)
Overall Dimension W470 x L583 x Height 890 (mm)
Net Weight: 60kg/132lb
Container Volume: 45 liters

Benefits

M01-SP Disinfectant Spraying Robot is developed to efficiently disinfect the environment by spraying non-industrial disinfectant, using the autonomous indoor navigation smart AI function to cover large areas, and protecting operators from contact with the chemical disinfectant.
The four nozzles provide a 3.2m width coverage when operating, and capable to cover an area of 300m2 within 30 minutes. The robot equips with multiple sensors including LiDAR and ultrasonic for simultaneous localization and mapping, with obstacle avoidance, to provide the highest safety during operation. The built-in battery provides a 4-hour continuous operating time and auto return for charging when low in power.

Success Stories

M01 AMR is approved by European Standard EN60601 as medical electrical equipment
